Model:
– Capacity: 1050VA/630W
Input :
– Voltage 220-240VAC
– Voltage Range 140-300 VAC
– Frequency: 50 / 60Hz
– Current :4.8A Max
Output:
– Voltage Regulation (Bat.Mode): +/-10%
– Frequency :50 / 60Hz
– Waveform: Simulated Sine wave
Battery:
– Battery Type: 12V / 9AH x 1
– Charging ability: 6 hours recover to 90% capacity
Transfer Time:
– Typical:2-6ms
Protection : Short circuit, Overload, Battery discharge and overcharge, Surge Protection
Indications:
– Line Mode: Green lighting
– Battery Mode :Yellow flashing
– Fault: Red Lighting
Audible Alarm:
– Battery Mode: Sounding every 10 sec
– Battery low :Sounding every 1 sec
– Overload : Sounding every 0.5 sec
– Fault: Continuous sounding
Environment:
– Humidity 0-90% relative Humidity 0-40°C (Non-condensing)
– Noise Level : Less than 40dB
– Dimension: 283mm x 101mm x 140mm
