• • Max. Resolution – 2.0MP (1920×1080)
  • Main Stream – PAL: 25fps (1920×1080, 1280×720, 704×576, 640×480) NTSC: 30fps (1920×1080, 1280×720, 704×480, 640×480)
  • Sub Stream – PAL: 25fps (704×576, 704×288, 640×360, 352×288) NTSC: 30fps (704×480, 704×240, 640×360, 352×240)
  • Third Stream – PAL: 25fps(704×576, 704×288, 352×288) NTSC: 30fps (704×480, 704×240, 352×240)
  • Image Setting – Saturation, brightness, contrast, sharpness, adjustable by client software or web browser
  • Image Enhancement – BLC/3D DNR/HLC
  • ROI – 7 Dynamic Areas for Both Main and Sub Stream
  • OSD – 16×16, 24×24,32×32, 48×48, 64×64, 96×96, adaptable size, Letters Such as Week, Date, Time,Total 5 Regions
  • Picture Overlay – Yes
  • Privacy Mask – Yes
  • Smart Defog – Yes

Feature

• • Alarm Trigger – Harsh Voice Alarm, Motion Detection, Mask Alarm, Port Alarm,Network Disable Alarm, IP Conflict, MAC Conflict Detection
  • Video Analytics – Tripwire, Double Tripwire, Perimeter, Object Abandon, Object Lost, Video Abnormal, Audio Abnormal, Face Capture
  • Early Warning(EW) – N/A
  • Auto-Tracking – N/A

Face Detection and Analytics

• • Operating Mode – Face capture, intelligent monitoring optional, default intelligent monitoring
  • Face Detection Performance – Detects up to 16 faces at the same scene
  • Face Exposure Brightness – Default 35, 1~100 brightness optional
  • Min. Face Pixel – Default 80, 19~1920 optional
  • Precautionary Alert – Three level
