Camera
- Image Sensor: 1/2.8″ Progressive Scan CMOS
- Max. Resolution: 3840 × 2160
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
- Shutter Time: 1/3 s to 1/100,000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°
Lens
- Lens Type: Fixed focal lens, 2.8, 4, and 6 mm optional
- Focal Length & FOV
- 2.8 mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128°
- 4 mm, horizontal FOV 87°, vertical FOV 46°, diagonal FOV 105°
- 6 mm, horizontal FOV 54°, vertical FOV 29°, diagonal FOV 63°
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F1.6
DORI
- DORI
- 2.8 mm: D: 88 m, O: 35 m, R: 17 m, I: 9 m
- 4 mm: D: 108 m, O: 43 m, R: 22 m, I: 11 m
- 6 mm: D: 177 m, O: 70 m, R: 35 m, I: 18 m
